Size		∅D	∅d	∅L	∅h1	∅h2	∅h3	Stem		Top flange to ISO 5211				O	WT(Kg)
inch	mm	∅D	∅d	∅L	∅h1	∅h2	∅h3	∅U	G	∅N	∅P	m	∅A	O	WT(Kg)
1.5	40	86	40	40	54	122	33	14	10	90	70	4	9	10	3.1
2	50	105	52	43	57	129	33	14	10	90	70	4	9	11	3.7
2.5	65	114	65	46	67	139	33	14	10	90	70	4	9	11	4
3	80	129	80	46	78	156	33	14	10	90	70	4	9	11	4.4
4	100	155	100	52	100	164	33	16	12	90	70	4	9	11	5.9
5	125	180	125	56	107	187	33	19	15	90	70	4	9	12	8.9
6	150	207	150	56	122	200	33	19	15	90	70	4	9	12	9
8	200	260	198	60	165	238	35	22	18	90	70	4	9	13	11
10	250	331	248	68	215	286	45	22	8x8	125	102	4	12	15	20
12	300	377	298	78	245	316	45	28	8x8	125	102	4	12	15	31.5
14	350	416	327	78	272	345	45	32	8x8	125	102	4	12	20	43
16	400	475	387	102	382	304	70	38	12x8	175	140	4	18	23	63.5
18	450	535	438	114	333	400	70	38	12x8	175	140	4	18	23	99
20	500	590	477	127	370	438	80	45	14x9	230	165	4	20	34	114.5
22	550	680	518	140	413	475	80	50	14x9	230	165	4	20	34	149.5
24	600	695	560	154	430	510	80	55	14x9	230	165	4	20	34	214.5
26	650	735	585	165	455	530	80	55	14x9	230	165	4	20	34	260
28	700	800	690	165	490	580	90	60	20x12	230	165	4	20	35	377
30	750	857	729	180	535	585	90	60	20x12	300	250	4	22	35	460
32	800	920	785	190	580	630	90	70	20x12	300	250	6	22	35	542
34	850	945	820	200	590	660	90	70	20x12	300	250	6	22	35	542
36	900	1000	870	203	650	700	100	75	22x14	300	250	6	22	38	699
40	1000	1095	960	216	700	750	100	85	22x14	300	250	6	22	40	977

Size		JIS 5K			KS. JIS 10K			JIS 16K(20K)			BS4504 PN10			BS4504 PN16			ANSI 150LB
inch	mm	∅C	F	∅E	∅C	F	∅E	∅C	F	∅E	∅C	F	∅E	∅C	F	∅E	∅C	F	∅E
1.5	40	95	4	15	105	4	19	105	4	19	110	4	18	110	4	18	95.5	4	16
2	50	105	4	15	120	4	19	120	8	19	125	4	18	125	4	18	120.5	4	19
2.5	65	130	4	15	140	4	19	140	8	19	145	4	18	145	4	18	139.5	4	19
3	80	145	4	19	150	8	19	160	8	23	160	8	18	160	8	18	152.5	4	19
4	100	165	8	19	175	8	19	185	8	23	180	8	18	180	8	18	190.5	8	19
5	125	200	8	19	210	8	23	225	8	25	210	8	18	210	8	18	216	8	22
6	150	230	8	19	240	8	23	260	12	25	240	8	18	240	8	23	241.5	8	22
8	200	280	8	23	290	12	23	305	12	25	295	8	23	295	12	23	298.5	8	22
10	250	345	12	23	355	12	25	380	12	27	350	12	23	355	12	27	362	12	25
12	300	390	12	23	400	16	25	430	16	27	400	12	23	410	12	27	432	12	25
14	350	435	12	25	445	16	25	480	16	33	460	16	23	470	16	27	476	12	29
16	400	495	16	25	510	16	27	540	16	33	515	16	27	525	16	30	539.5	16	29
18	450	555	16	25	565	20	27	605	20	33	565	20	27	585	20	31	578	16	32
20	500	605	20	25	620	20	27	660	20	33	620	20	27	650	20	33	635	20	32
24	600	715	20	27	730	24	33	770	24	39	725	20	30	770	20	36	749.5	20	35
28	700	820	24	27	840	24	33	875	24	42	840	24	30	840	24	36	863.6	28	35
30	750	880	24	33	900	24	33	935	24	42	-	-	30	-	-	-	914.4	28	35
32	800	930	24	33	950	28	33	990	24	48	950	24	33	950	24	39	978	28	41
36	900	1030	24	33	1050	28	33	1090	28	48	1050	28	33	1050	28	39	1086	32	41
40	1000	1130	28	33	1160	28	39	1210	28	56	1160	28	36	1170	28	42	1200	36	41
